L3OUT Static Ver 4.2(2f)

CONFIGURATION

CONFIGURATION

0. Route Reflector

1. Access Policy

Fabric > Access Policies >

1) VLAN Pool
Pools > VLAN
- Create VLAN Pool
  - Name
  - Allocation Mode
  - Encap Blocks

2) Domain
Physical and External Domains > L3 Domains
- Create L3 Domain
  - Name
  - VLAN Pool

3) AEP
Policies > Global > Attachable Access Entity Profiles
- Create Attachable Access Entity Profiles
  - Name
  - Domains

4) Interface Policy
Policies > Interface > XXXXX
- Create XXXXX

5) Interface Policy Group
Interfaces > Leaf Interfaces > Policy Groups > Leaf Access Port
- Create Leaf Access Port Policy Group
  - Name
  - Attached Entity Profile
  - XXXXX

6) Interface Profile
Interfaces > Leaf Interfaces > Profiles
- Create Leaf Interface Profile
  - Name
  - Interface Selectors
    - Name
    - Interface IDs
    - Interface Policy Group

7) Switch Profile
Switches > Leaf Switches > Profiles
- Create - Leaf Profile
  - Name
  - Leaf Selectors
    - Name
    - Blocks
  - Interface Selector Profiles

2. L3OUT

Tenants > XXXXX > Networking > L3Outs
- Create L3 Out

1.Identity
- Name
- VRF
- L3 Domain
- No check for "Use for GOLF"
- No check the "BGP/EIGRP/OSPF"

>>> Next

2.Nodes And Interfaces
- Use Defaults (プロファイル名を自動作成するか否か)
- Interface Types
- Nodes
  - Node ID
  - Router ID
  - Loopback Address (Router ID入力で自動反映されるので削除)
  - Interface
  - IP Address

>>> Next

3.External EPG
- Name
- Provided Contract
- Consumed Contract
- Default EPG for all external networks
  (チェック有りだと0.0.0.0/0が入力されたのと同じ)

ウィザードが終わってもStatic 自体は入力していないので別途、必要

Tenants > XXXXX > Networking > L3Outs > XXXXX > Logical Node Profiles > XXXXX
 > Configured Nodes > Node Association

WorkペインのStatic Routesに追加
