Virtual Port Channel Ver 4.2(2f)

スポンサーリンク
スポンサーリンク

CONFIGURATION

1. Access Policy

Fabric > Access Policies >

1) VLAN Pool
Pools > VLAN
- Create VLAN Pool
  - Name
  - Allocation Mode
  - Encap Blocks

2) Domain
Physical and External Domains > Physical Domains
- Create Layer 3 Domain
  - Name
  - VLAN Pool

3) AEP
Policies > Global > Attachable Access Entity Profiles
- Create Attachable Access Entity Profiles
  - Name
  - Domains

4) Interface Policy
Policies > Interface > Port Channel
- Create Port Channel Policy
  - Name
  - Mode

5) Interface Policy Group
Interfaces > Leaf Interfaces > Policy Groups > VPC Interface
- Create VPC Interface Policy Group
  - Name
  - Attached Entity Profile
  - Port Channel Policy

6) Interface Profile
Interfaces > Leaf Interfaces > Profiles
- Create Leaf Interface Profile
  - Name
  - Interface Selectors
    - Name
    - Interface IDs
    - Interface Policy Group

7) Switch Profile
Switches > Leaf Switches > Profiles
- Create - Leaf Profile
  - Name
  - Leaf Selectors
    - Name
    - Blocks
  - Interface Selector Profiles

8) Virtual Port Channel Security Policy
Policies > Switchs > Virtual Port Channel default
- Pairing Type : explicit
- Explicit VPC Protection Groups :
  - Name
  - ID
  - VPC Domain Policy : default
  - Switch 1
  - Switch 2



2. Tenant 設定

Tenants > XXXXX > Application Profiles > XXXXX > Application EPGs > XXXXX > Static Ports
Deploy Static EPG on PC, VPC, or Interface
- Port Type : Virtual Port Channel
- Path :



REFERENCE

Virtual Port Channel (VPC) Load Balancing Algorithms
